LS 5000 Ride-on Airless Line Striper Airless Cold Paint Road Marking Machine

Short Description:

Best Ride-on Athletic Striper Available LS 5000 has been designed with many features that make striping athletic fields as easy and efficient as possible. With its compact design, the LS 5000 saves money while maintaining the professional level of line quality that the Andersen striping line has become known for.

Send email to us

Product Detail

Product Tags

Product Features

Easy Clean up:You clean the spray gun and hose right in the field. The in-line filter keeps you running without clogs. Paint Efficiency: SAVE 30% ON PAINT COSTS. The Andersen's 3000 PSI, high-pressure airless pump atomizes paint more efficiently than other
lower pressure stripers. This allows for nearly 30% more coverage per gallon of paint at 450 linear feet per gallon. This makes
the NewRider stripers the most efficient ride-on athletic field stripers available. Floating Spray Head: The floating spray head
allows for even lines on even the most bumpy of fields. Equipped with a pneumatic wheel that leads the spray gun, the floating
head keeps a consistent spray pattern over any dips and bumps that afield may have.

Technical Parameters

Code	Parameter		QTY	Outer box size	G.W/N.W
LS 5000	Gasoline	Honda GX160	1	126X78X98 cm	160KG
	Power:	6.0HP
	Max Pressure	22Mpa
	Max Tip Size	0.025''( two guns)
	Max Flow	4.5LPM
	Motor	Brushless motor

Benefits

Easy Clean UP – On-board 2.5 gallon purge tank lets you clean spray gun and hose in the field. In-line filter keeps you running without clogs. Convenience and Comfort – The two position high back seat with operator controls for ignition, throttle and parking brake and a cup/cell phone holder, keeps everything within arms reach. Seat-based foot pedals control forward/reverse, speed,spray gun activation, steering column lock, and lifting or lowering the spray head. Efficiency– Save time and money. The 25 gallon paint tank enables for coverage of 5 soccer fields or 2.5 football field on a single tank. The 3000 PSI high-pressure airless pump atomizes paint into a fine mist. This enhances paint coverage efficiency by 30% when compared to lower pressure machines. Provides for a 450 linear feet per gallon coverage when spraying a 4” wide line.
